BLE HC-10 Bluetooth

The BLE HC-10 Bluetooth Module is a versatile and low-power solution for wireless communication. It supports Bluetooth 4.0 BLE, making it ideal for applications requiring efficient data transmission over short distances.

Categories: , , , Tags: , , ,

Description

Description

The BLE HC-10 Bluetooth Module is a versatile and low-power solution for wireless communication. It supports Bluetooth 4.0 BLE, making it ideal for applications requiring efficient data transmission over short distances. The module operates in the 2.4GHz ISM band and uses GFSK modulation for reliable communication. It features a simple UART interface for easy integration with microcontrollers and other devices.

Specifications:

  • Bluetooth Version: 4.0 BLE
  • Operating Voltage: 2.5V to 3.3V
  • Current Consumption: Active state 8.5mA, Sleep state 50~200uA
  • RF Power: -23dBm to 6dBm
  • Working Frequency: 2.4GHz ISM band
  • Dimensions: 27mm x 13mm x 2.2mm
  • Communication: UART interface
  • Security: Authentication and encryption123.
