TCRT5000 IR Distance Sensor (4 Pin)

$2,00 inc. IVA

The TCRT5000 is a reflective optical sensor that combines an infrared emitter and a phototransistor in a compact leaded package. With a peak operating distance of 2.5 mm and an operating range spanning 0.2 mm to 15 mm, it’s ideal for position sensing, reflective material detection (such as paper or magnetic tapes), and limit switches.

4 in stock

Categories: , Tags: , ,

Description

The TCRT5000 IR Distance Sensor with Analog output pin is a reflective optical sensor that includes an infrared emitter and phototransistor in a compact package. It is designed for proximity sensing and object detection, making it ideal for applications such as line-following robots and obstacle detection. The sensor operates by emitting infrared light and detecting the reflection from nearby objects, providing an analog output proportional to the distance.

Specifications:

  • Operating Voltage: 5V
  • Peak Operating Distance: 2.5mm
  • Operating Range: 0.2mm to 15mm
  • Typical Output Current: 1mA
  • Emitter Wavelength: 950nm
  • Dimensions: 10.2mm x 5.8mm x 7mm
  • Features: Daylight blocking filter, lead-free soldering123
